Functions
X TC160 automates the entire process of material sorting, carton forming, liner positioning, and robotic loading of cartons/instructions. Equipped with inspection units, it performs barcode scanning, missing item detection, and integrates with a rejection system. Featuring a modular design with full servo drive, it operates at noise levels below 80dB and adheres to ergonomic principles. It supports rapid changeovers for two types of cartons/liners/injection pens, achieving a single-dose output of 160 units/min and multi-dose output of 40 cartons/min. Capable of continuous operation exceeding 16 hours/day, it balances high efficiency with operational stability.
Features
Online Forming System
Compatible with Multiple SKUs
SCARA Robot
MTTR<2 Minutes
In-line Production
Easy Maintenance
Quick Changeover
Easy Operation
Technical Specs
Parameter | Value |
Line Voltage | 380V, 50/60Hz, 3P+PE |
Rated Current | 200A |
Power Supply Tolerance | ±10%, ±1Hz |
Control Voltage | 24V DC |
Compressed Air Pressure | 6-8 bar |
Compressed Air Consumption | 14000 L/h |
Humidity | 30%-75% RH (non-condensing) |
Temperature | 10°C - 25°C |
Product Specification | Pre-filled syringes or cartridges, single piece |
Stable Operating Speed | 160 cartons /min |
Speed Range | 0-160 cartons/min. |
Equipment Dimensions | 19132mm(L) x 5412mm(W) x 2710mm(H) |
Equipment Weight | Approx. 30 tons |
Process Flow Diagram
